Product Image
Specifications
Features
Instructions for use

电焊台

category	project	TGK-S906D	TGK-S909D
Function parameter	Rated input voltage	AC 220V 50Hz	AC 220V 50Hz
	rated power	60 W	90 W
	The output voltage	24V	24V
	Maximum instantaneous power	Less than 80W	Less than 150W
	Standby power consumption	Less than 6W	Less than 6W
	Adjustable temperature range	100-500 ° C	100-500 ° C
	Temperature correction	Digital school temperature	Digital school temperature
	Digital display / temperature adjustment	LCD display, intelligent operation	LCD display, intelligent operation
	Power saving function	Intelligent sleep	Intelligent sleep
	Low temperature alarm function	Intelligent alarm	Intelligent alarm
	Temperature lock mode	smart Lock	smart Lock
	Tip to ground resistance	<2 ohms	<2 ohms
	Tip to ground potential	<2mV	<2mV
Characteristic parameter	Heating time Normal temperature -350°	<50S	<10S
	Temperature deviation	±1° C (after temperature correction)	±1° C (after temperature correction)
	Temperature stability	±2°C (no load)	±2°C (no load)
	Warm back time	<3S	<3S
	Heating core life	>5000H (constant temperature 350 °C)	>1000H (constant temperature 350 °C)
Component characteristics	transformer	7640 copper	7640 copper
	Heater	Ordinary 4-core stainless steel heater	Advanced silver alloy heater
	Handle line	Silicone, Teflon	Silicone, Teflon
	shell	raw material	raw material
	Iron frame	High quality bakelite	High quality bakelite
	Iron mouth	TGK-900M series	TGK-LT series
	Circuit configuration	MCU temperature control	MCU temperature control
Performance overview	窗体顶端窗体顶端窗体顶端 High-performance MCU chip, PID temperature control, rapid heating and temperature recovery, true lead-free soldering; 12864LCD large-screen display, intelligent operation; digital temperature, fast access, fault alarm; work information at a glance 窗体底端窗体底端窗体底端

1. High-performance, low-power AVR microprocessor, PID technology temperature control

2. Full power pure copper transformer, high efficiency, low heat generation and low loss

3. Silver alloy heating core, high heat conduction effect

4. Warming back to temperature, 10s can work, continuous welding effect is good

5. The tip of the soldering iron is designed to reduce the consumables and save the cost of use.

6. Heated core plug-in design, easy to replace
