Product Image
Specifications
Features
Instructions for use

电焊台

category	project	TGK-809D
Function parameter	Rated input voltage	AC 220V 50Hz
	rated power	75 W
	The output voltage	27V
	Maximum instantaneous power	Less than 165W
	Standby power consumption	Less than 6W
	Adjustable temperature range	200-450 ° C
	Temperature correction	±99 (°C, °F)
	Digital display / temperature adjustment	digital display
	Power saving function	yes
	Low temperature alarm function	yes
	Temperature lock mode	Electronic (smart card)
	Tip to ground resistance	<2 ohms
	Tip to ground potential	<2mV
Characteristic parameter	Heating time Normal temperature -350°	<60S
	Temperature deviation	±5° C (after temperature correction)
	Temperature stability	±10°C (no load)
	Warm back time	<2S
	Heating core life	>5000H (constant temperature 350 °C)
Component characteristics	transformer	6645 copper
	Heater	Ceramic A1321
	Handle line	Silicone, Teflon
	shell	metal
	Iron frame	High quality bakelite
	Iron mouth	TGK-900M series
	Circuit configuration	MCU temperature control
Performance overview	窗体顶端 The price is moderate and the performance is stable; the 75W power and ceramic heater can ensure the soldering station has strong temperature recovery and continuous welding capability; the 3-digit digital display real-time temperature, practical sleep mode and electronic temperature mode. It is a soldering station with high cost performance. 窗体底端

1. Intelligent identification of large and small solder joints, excellent thermal compensation function, providing different temperature compensation for efficient lead-free soldering

2. With power-saving function, this function can be set internally for 15 minutes, the temperature is automatically reduced to 200 °C, avoiding excessive temperature oxidation of the soldering iron for a long time, or set to stand for 30 minutes, the power of the heating element will be automatically turned off.

3. The temperature correction value of the ultra-wide range (±99°C). When there is an error between the actual temperature of the tip and the set temperature, only the correction value is input, and the soldering station will correct the temperature of the soldering nozzle.

4. There is a low temperature alarm device. When the temperature of the soldering tip is lower than the minimum alarm range, the soldering station will sound an alarm signal, prompting the staff to check.
